Design Solution: A series of physical study models were used to investigate the site and the relationship of the new house to the Foster extension, while focusing on a strong sense of reciprocity between the two. This led to an approach where the form and volumes of new and old elements were both of similar architectural stature yet clearly delineated in the design. It also encouraged optimizing the relationship of Reciprocal House with its surrounding landscape, especially the tall mature trees surrounding its roof terrace.

The roof evokes the profile of the original cottage, while the distinct angled elevations give the architecture a strong geometric quality. This is further emphasized by the 6½-foot diameter circular skylight over the spiral aluminum staircase that connects the three main floors and can be fully opened for natural ventilation. The facades of the new building are sheathed in perforated aluminum mesh in a copper tone, preserving the memory of the original house while also providing privacy and screening from solar gain.

Photo © Schnepp Renou

Structure and Materials: Based on the very difficult access restrictions and structural requirements of the angled walls, new concrete elements were made in situ and leave the concrete visually exposed throughout to reduce the use of finishes, temper the light, and benefit from the thermal mass. The structure was optimized to allow for the thinnest wall and floor build ups. The interiors are paced with highly crafted aluminum elements—staircase, kitchen units, wardrobes, bathroom fittings, screens, and doors—designed by Gianni Botsford Architects and made in East London.

Additional Information
Completion date: August 2023
Site size: .062 acres
Total construction cost: Withheld
Client/Owner: Withheld

Photos © Schnepp Renou

Images courtesy Gianni Botsford Architects; click to enlarge
